The BK Racing Short Chain Balance Shaft Delete Sleeve System

Rather than relocating factory components, BK Racing developed a complete sleeve system designed specifically for Ecotec balance shaft removal.

Our system consists of both Inner Balance Shaft Delete Sleeves and Outer Balance Shaft Delete Sleeves, each engineered to perform a specific function while maintaining the integrity of the engine’s oiling system.

The Inner Sleeves install inside the factory inner bearing races to permanently block the oil passages while allowing the factory bearing races to remain exactly where GM installed them.

The Outer Sleeves replace the factory outer bearing assemblies and are precision-machined to install in their intended location.

Together, these components complete the balance shaft delete while maintaining the oiling system without relying on relocating factory bearing races.

Why We Leave the Factory Bearing Race in Place

One of the most common methods used throughout the industry involves driving the factory inner bearing race deeper into the block until it covers the oil passage.

While this method can work when performed correctly, it requires moving a factory-installed component from its original position.

Over the years we’ve heard numerous stories from builders who encountered problems during this process.

Some bearing races were driven in crooked.

Others cracked during installation.

Some appeared to be seated correctly only to move later in service.

Rather than asking builders to modify the position of a factory-installed bearing race, we engineered our Inner Sleeves to install inside the existing bearing race.

The factory bearing remains exactly where GM intended.

The sleeve performs the sealing function.

We believe this creates a more controlled and repeatable installation while reducing the chance of installation-related problems.

Engineered to Remove Installation Variables

Both the BK Racing Inner and Outer Balance Shaft Delete Sleeves were engineered with one objective:

Make the installation as repeatable as possible.

Unlike methods that depend on relocating bearing races or determining how far a plug should be driven into the block, our sleeve system installs in its intended location.

The design removes much of the guesswork from the installation process.

The sleeves are precision-machined to extremely tight tolerances to create a secure interference fit.

For installation, we recommend freezing the sleeves overnight. As they cool, they contract slightly, allowing them to install more easily. Once they return to room temperature, they expand back to their original dimensions, creating a tight, secure fit.

Each sleeve also features:

• Precision-machined interference fit
• Tapered lead for easier alignment during installation
• Threaded center for installation or future removal using common tools
• Designed to install in the correct position without measuring installation depth

These design features were developed from real-world experience building Ecotec race engines—not simply adapting a generic plug to fit the application.

Is Complete Balance Shaft Removal Right for You?

Complete balance shaft removal is an excellent choice when the engine is already completely apart.

However, it isn’t always the best option for every build.

If your engine is already assembled or you’re performing a refresh without stripping the block completely, the BK Racing Short Chain Balance Shaft Delete is often the more practical solution.

The right balance shaft delete depends on the stage of your build.

• Engine assembled? Consider the BK Racing Short Chain Balance Shaft Delete.
• Bare block rebuild? Complete balance shaft removal with BK Racing Inner and Outer Delete Sleeves is an excellent long-term solution.

Common Mistakes During Complete Balance Shaft Removal

Most problems associated with complete balance shaft removal aren’t caused by removing the shafts.

They’re caused by improper installation.

Common mistakes include:

• Forgetting to seal the required oil passages.
• Driving the factory bearing race in crooked.
• Cracking the bearing race during installation.
• Using improvised plugs that don’t positively locate.
• Installing components at the wrong depth.
• Failing to verify the oiling system before final assembly.

Understanding the engineering behind the modification is just as important as performing the modification itself.

The Bottom Line

Complete Ecotec balance shaft removal is an excellent option for builders performing a complete engine rebuild.

When completed correctly, it simplifies the engine while eliminating unnecessary rotating components that no longer serve a purpose in many performance applications.

Just as importantly, the engine’s oiling system must be completed correctly.

At BK Racing, that philosophy led us to develop our complete Balance Shaft Delete Sleeve System.

Rather than relying on relocated bearing races or generic plugs, our Inner and Outer Sleeves were engineered specifically for the Ecotec platform to provide a controlled, repeatable installation while maintaining the integrity of the factory oiling system.

For us, that’s what engineering is all about.

Not simply removing parts.

Designing a better solution.

Frequently Asked Questions

Can I simply remove the balance shafts?

No. Once the balance shafts are removed, the engine’s oil passages must be addressed correctly to maintain proper oil routing.

Do I need balance shaft delete plugs?

Many builders search for “balance shaft delete plugs,” but there are several methods of sealing the oil passages. BK Racing uses precision-machined Inner Balance Shaft Delete Sleeves that install inside the factory bearing race rather than relocating it.

Why doesn’t BK Racing recommend moving the factory bearing race?

While moving the bearing race can work, it introduces additional installation variables. BK Racing designed the Inner Sleeves to seal the oil passages while allowing the factory bearing race to remain in its original location.

Can the BK Racing Sleeves be removed?

Yes. The threaded center allows the sleeves to be removed using common tools if future engine service requires it.

Continue Learning: What Does an Ecotec Balance Shaft Delete Actually Change?

Understanding how the GM Ecotec balance shaft system works is the first step in deciding whether a balance shaft delete is right for your engine. As you've learned, GM engineered the system to reduce second-order engine vibration and improve refinement in production vehicles. However, the demands placed on a dedicated race engine are very different from those of a daily driver, which is why many performance builders choose to remove the balance shaft assembly entirely.

Not all balance shaft deletes are the same. Cut shafts, neutral balance shafts, complete balance shaft removal, and short-chain delete systems each affect the engine differently. Choosing the right approach depends on your performance goals, intended use, and how the engine will be operated.

Whether you're performing a complete balance shaft delete or a short-chain conversion, selecting the correct components is just as important as understanding the modification itself. Depending on your chosen method, you may need BK Racing Complete Balance Shaft Delete Kit, Outer Balance Shaft Bushings, Inner Balance Shaft Delete Sleeves, Modified Upper Short Chain Guide, Shortened Water Pump Chain, and other supporting components to complete the installation properly. If you're performing a complete delete, don't forget to add the BK Racing Inner Balance Shaft Delete Sleeves to your order—they're a required part of a proper installation.

The next guide explores what actually changes after removing the balance shaft assembly, including rotating mass, parasitic losses, vibration, engine reliability, and why balance shaft deletes have become a common modification in naturally aspirated, turbocharged, supercharged, and circle track GM Ecotec engines.
